Setting up a Brother scanner doesn’t have to be complicated. Whether you’re using a portable DS-610 or a desktop MFC-L2710DW, this guide walks you through every step from initial driver installation to advanced features like scan-to-email and network folder scanning. The primary keyword “how to set up Brother scanner” is central to your search, and we’ve optimized this guide to deliver exactly what you need: clear, actionable steps without fluff.
You’ll learn how to connect your scanner via USB or Wi-Fi, install the correct drivers, configure one-touch scanning, and troubleshoot common issues. Whether you’re on Windows or macOS, using a home network or small office setup, these procedures are tested across multiple Brother models and OS versions. By the end, your scanner will be fully functional ready to scan to PC, email, or network folders with ease.
Connect via USB First
Before going wireless, use a USB connection to install drivers and configure settings. This method ensures a stable foundation for your scanner setup.
Use Correct USB Cable
• Plug in your Brother scanner using a micro USB 2.0 or 3.0 cable
• Connect directly to your computer. Avoid USB hubs or extension cables
• Ensure the Mode Select Switch (if present) is set to USB mode
Warning: For models like DS-610, install the driver before connecting the scanner. Otherwise, Windows may install incomplete drivers.
Install Full Driver Package
- Go to support.brother.com
- Select your country and language
- Enter your model number (e.g., MFC-L2710DW)
- Download the Full Driver & Software Package
- Run the installer as Administrator
Choose Wireless Connection
Even if setting up Wi-Fi, start with USB. Select Wireless Network Connection (Wi-Fi) during installation. The installer uses the USB link to send Wi-Fi settings to the scanner. Once connected, you can unplug the USB cable permanently.
Configure Wi-Fi Using Installer
The easiest way to connect your Brother scanner to Wi-Fi is through the full driver installer. This method handles network configuration automatically.
Detect Available Networks
After selecting Wi-Fi setup, the installer scans for nearby networks. If your network appears, select it and click Next. If not visible, choose “connect to another wireless network.”
Enter Hidden Network Manually
For hidden SSIDs, click Advanced and manually enter the Network Name (SSID), Authentication Method (usually WPA2-Personal), Encryption Mode, and Network Key (password).
Tip: Double-check password case and special characters. Wi-Fi keys are case-sensitive.
Confirm Settings and Switch Mode
• Review displayed settings and click Next
• When prompted, change the Mode Select Switch from USB to Wi-Fi
• Wait for the Wi-Fi LED to turn solid blue
Red or blinking light indicates connection failure. Reboot your router and scanner, then retry.
On-Device Wi-Fi Setup (No PC Needed)
For models like HLL2390DW or MFC-L2710DW, configure Wi-Fi directly from the control panel without using a computer.
Use Setup Wizard
- Press Menu on the control panel
- Navigate to Network → OK
- Choose WLAN → Setup Wizard → OK
- Wait for the list of available networks
- Select your SSID and press OK
- Enter your password using arrow keys and press OK after each character
- Confirm with Yes
Success sign: Wi-Fi LED stays solid blue.
Use WPS for Faster Connection
If your router supports WPS, press the WPS button on your router. Within 2 minutes, press and hold the Wi-Fi button on your scanner until it blinks. The device connects automatically.
WPS takes under 30 seconds and avoids typing passwords.
Install Scanner Drivers Correctly
Drivers are essential for full functionality, especially scan-to-PC and network features. Proper installation ensures you access all scanning capabilities.
Windows: Full Installation Steps
- Run the downloaded installer
- Accept the License Agreement
- Choose Complete Installation for all features
- When User Account Control (UAC) appears, click Allow
- Follow prompts in the SCANNER CONNECTION window
Never skip UAC prompts. This prevents driver installation failures.
Verify Installation
After setup, open Settings → Devices → Printers & Scanners. Click Add a printer or scanner and wait for Brother [Model] to appear. Click Add device. Once added, go to Devices and Printers, right-click your Brother scanner, and select Open Scanner.
macOS: Built-in Support Plus Optional Apps
macOS uses Image Capture or Preview by default. Plug in your scanner or connect over Wi-Fi, then open Image Capture. Your Brother device should appear automatically.
For full features, download Brother iPrint&Scan or Scanner Driver, install it, and restart your computer. This gives you access to advanced tools like OCR and batch scanning.
Scan Directly from Control Panel
Use the physical buttons on your Brother scanner for fast, one-touch scanning. This method works without needing a computer nearby.
Place Document Correctly
Use the flatbed for single pages or fragile documents. Use the ADF (Automatic Document Feeder) for multi-page scans if your model includes this feature.
Select Scan Destination
Press the Scan button, then choose from these options:
• Scan to PC
• Scan to Email
• Scan to USB (if USB drive inserted)
• Scan to Cloud (if configured)
Adjust Basic Settings
Before scanning, choose Color or Black & White. Set Resolution (300 DPI recommended for text). Pick File Type (PDF for documents, JPEG for images).
Pro Tip: Save your favorite settings as a shortcut for reuse.
Set Up Scan-to-Email (One-Touch Sending)
Send scanned documents directly to email with one press. This feature is ideal for offices where documents need immediate distribution.
Register Email Account
- On the control panel, go to Apps → Easy Scan to Email
- Select Edit Account → Register Account
- Enter the recipient email (e.g., admin@company.com)
- Assign a display name (e.g., “To HR”)
Enable PIN Protection (Optional)
For shared offices, turn on PIN Protection and set a 4-digit PIN. Users must enter the PIN before sending scans.
Configure Scan Settings
| Setting | Recommended Value |
|---|---|
| File Type | PDF (multi-page) |
| Resolution | 300 DPI |
| Color Mode | Color |
| Subject Line | “Scanned Document – [Date]” |
Note: Use app-specific passwords for Gmail with 2FA enabled.
Create One-Touch Shortcut
- After setup, select Yes when asked to create a shortcut
- Choose an available shortcut button
- Name it (e.g., “Invoice to Accounting”)
- Press OK
Now just press the button, place the document, and hit Start.
Configure Scan to Network Folder
Scan directly to a shared folder on your PC. This is ideal for offices where multiple people need access to scanned documents.
Create Local User Account
Avoid permission errors by creating a dedicated local account:
- Open Settings → Accounts → Family & other users
- Click Add account → I don’t have sign-in info
- Choose Add a user without Microsoft account
- Set a username, password, and recovery info
- Click Next
This account must have a password, not a PIN.
Share Scan Folder
- Create a folder named Scans on your desktop
- Right-click → Properties → Sharing tab
- Click Share, add your username, and set to Read/Write
- Click Advanced Sharing and check “Share this folder”
- Under Permissions, give the user Full Control
Set Network to Private
- Go to Settings → Network & Internet → Properties
- Change the profile to Private
Public networks block file sharing.
Access Web Interface
- Print a Configuration Page (Menu → Print Reports → Configuration Page)
- Note the IPv4 Address (e.g., 192.168.1.100)
- Open your browser and enter the IP address
Log In and Configure
Log in with username “admin” and password “initpass” (case-sensitive). Go to the Scan tab → Scan to Network → select Profile 1. Enter the Profile Name, Network Path (e.g., \192.168.1.50\Scans), Username & Password, Resolution, and File Type. Click Submit.
Test the Scan
Place a document, press Scan, choose your profile, and check the Scans folder for the new file.
Success means no authentication errors and the file appears instantly.
Use Windows Fax and Scan
Use this built-in Windows tool as an alternative method for scanning documents.
Enable the App (Windows 11)
- Settings → System → Optional features
- Click View features
- Find Windows Fax and Scan
- Install if missing
Start a Scan
- Open Windows Fax and Scan
- Click New Scan
- Select your Brother scanner
- Choose color, resolution, and file type
- Click Scan
Fix If Scanner Not Detected
Press Win + R, type services.msc, and find Windows Image Acquisition (WIA). Right-click and select Start if it’s stopped. Set Startup type to Automatic.
This service is required for most scanning apps.
Install Brother iPrint&Scan
This app provides the best control and mobile access for your Brother scanner.
Download and Install
- Visit support.brother.com
- Search for iPrint&Scan
- Download for Windows or macOS
- Run the installer and follow prompts
Connect to Scanner
- Launch the app
- Click Select Your Machine
- Wait for device detection
- Choose your model and click OK
If not found, reboot your router, scanner, and computer in that order, then retry.
Use Remote Features
• Scan to PC
• Print from phone
• Copy documents
• Check toner levels
This app is also available for iOS and Android.
Troubleshoot Common Issues
Fix problems fast with these targeted solutions.
Scanner Works on Device but Not from PC
Cause: WIA service disabled or driver conflict
Fix: Open services.msc, start Windows Image Acquisition (WIA), set it to Automatic, and reinstall the Full Driver & Software Package.
Device Not Detected During Setup
Solutions:
• Use direct USB connection (no hubs)
• Disable firewall/antivirus temporarily
• Reboot all devices in order: router → scanner → PC
• Try setup again
Scan to Network Fails with Authentication Error
Most common causes:
• Network set to Public
• User account uses PIN or Microsoft account
• No Full Control permissions
Fix: Set network to Private, use local account with password, and grant Full Control in folder permissions.
Scan Button Not Responding (e.g., MFC-L2710DW)
Check: Driver installed? Wi-Fi connected? Firmware up to date? Control panel frozen?
Solutions: Reinstall driver, reconnect to Wi-Fi, update firmware via web interface, or perform a soft reset (unplug for 15 seconds).
Scan-to-Email Not Working
Verify: SMTP settings correct? Email password valid? Internet access confirmed? Firewall blocking email?
Test with a different email provider if needed.
Poor Scan Quality
Improve quality by:
• Increasing resolution to 300 DPI
• Choosing Color mode
• Cleaning scanner glass with lint-free cloth
• Flattening crumpled documents
Avoid scanning through plastic sleeves. They cause glare.
Maintain and Optimize Performance
Keep your Brother scanner running smoothly with regular maintenance.
Clean Regularly
Wipe the scanner glass weekly with a soft, dry cloth. Clean ADF rollers monthly with a roller cleaning sheet. Avoid alcohol or harsh cleaners.
Update Firmware and Drivers
Check for updates every 3 to 6 months. Visit support.brother.com, enter your model, and download the latest firmware.
New firmware often fixes bugs and improves Wi-Fi stability.
Label Shortcuts Clearly
Use descriptive names like “To Payroll,” “Client Contracts,” or “Scan to Dropbox.” Avoid generic names like “Shortcut 1.”
Test Monthly
Run a test scan to PC, email, and network folder. This ensures all functions work before you need them.
Frequently Asked Questions About Brother Scanner Setup
How do I find my Brother scanner model number?
The model number is located on a label on the front or back of your device. You can also find it in the documentation that came with your scanner or by checking the Brother support website.
Can I set up my Brother scanner without a CD?
Yes. You can download the Full Driver & Software Package from support.brother.com. This is the recommended method as it provides the most up-to-date drivers and software.
Why is my Brother scanner not detected on Wi-Fi?
This usually happens due to network configuration issues. Try rebooting your router, scanner, and computer in sequence. Make sure your network is set to Private, not Public. Also verify the Wi-Fi LED shows a solid blue connection.
Do I need to install drivers for macOS?
macOS has built-in support through Image Capture and Preview. However, installing Brother iPrint&Scan or the Scanner Driver provides full functionality including OCR and batch scanning features.
How do I update my Brother scanner firmware?
Visit support.brother.com, enter your model number, and look for firmware updates in the downloads section. You can also access firmware updates through the scanner’s web interface or Brother iPrint&Scan app.
What resolution should I use for scanning documents?
300 DPI is recommended for most documents. Use higher resolutions (600 DPI) only when scanning photos or documents requiring extreme detail. Higher resolutions create larger file sizes.
Key Takeaways for Setting Up Your Brother Scanner
Setting up a Brother scanner is straightforward when you follow the right steps. Always use the Full Driver & Software Package from Brother’s official website rather than relying on automatic Windows installations. Connect via USB first during Wi-Fi setup, as the installer uses this connection to send network settings to your scanner.
Configure scan destinations like email and network folders for maximum efficiency. Use the control panel shortcuts for one-touch scanning to save time on repetitive tasks. Keep your drivers and firmware updated every few months to maintain optimal performance and security.
With proper setup and regular maintenance, your Brother scanner will deliver reliable performance for years whether you’re working from home or in a busy office environment.
